“The 8800 Series Narrow Stile Rim Exit Device is designed for
narrow stile aluminum applications that require a life-safety exit
device with Starwheel interlocking solution. Designed for use in
applications with single doors or pairs of doors with a mullion.
More Details Below
Certifications UL 305 Panic Hardware
ANSI/BHMA A156.3-2008 Grade 1
ANSI/BHMA A156.3-2014 Grade 2
Materials Push bar made of extruded aluminum,
clad or anodized in a variety of finishes
Handing Device is non-handed.
Push bar Length
Standard size: 36″” [914.4 mm] Standard width bars can be field cut to the next smallest opening width.
Door Thickness Suits 1-3/4″” [44.5 mm] standard, up to 2-1/4″” [57.2 mm].
Stile Width Minimum 2″” [50.8 mm] stile. Fits narrow, medium, and wide stile aluminum doors
Projection 2-5/8″” [66.7 mm] when fully projected,
1-5/8″” [41.3 mm] when dogged.
Dogging Standard dogging with hex key or optional cylinder dogging.
Fasteners Standard machine screws.
Cylinders Fits any standard 1-5/32″” [29.4 mm] diameter rim cylinder
Strike Standard strike and narrow
versions for centering doors in 4″”
jamb (both strikes included).”
$385.00 $308.00
“The 8800 Series Narrow Stile Rim Exit Device is designed for
narrow stile aluminum applications that require a life-safety exit
device with Starwheel interlocking solution. Designed for use in
applications with single doors or pairs of doors with a mullion.
More Details Below Certifications UL 305 Panic Hardware
ANSI/BHMA A156.3-2008 Grade 1
ANSI/BHMA A156.3-2014 Grade 2
Materials Push bar made of extruded aluminum,
clad or anodized in a variety of finishes
Handing Device is non-handed.
Push bar Length
Standard size: 36″” [914.4 mm] Standard width bars can be field cut to the next smallest opening width.
Door Thickness Suits 1-3/4″” [44.5 mm] standard, up to 2-1/4″” [57.2 mm].
Stile Width Minimum 2″” [50.8 mm] stile. Fits narrow, medium, and wide stile aluminum doors
Projection 2-5/8″” [66.7 mm] when fully projected,
1-5/8″” [41.3 mm] when dogged.
Dogging Standard dogging with hex key or optional cylinder dogging.
Fasteners Standard machine screws.
Cylinders Fits any standard 1-5/32″” [29.4 mm] diameter rim cylinder
Strike Standard strike and narrow
versions for centering doors in 4″”
jamb (both strikes included).”
$377.00 $301.60
“Sirenlock Model 250 is a UL Listed panic alarm deadbolt devices that restrict unauthorized use of exit doors by sounding an alarm while providing instant egress in emergencies SPECIFICATIONS:
FUNCTION Weather-Resistant Alarmed Panic Lock
COVER
Die-Cast Metal
PUSH BAR
Extruded Aluminum channel and push bar
LENGTH Paddle
HANDING Non-handed
INSTALLATION
Surface-mounted for single or double doors
CYLINDER Accepts most standard size rim cylinders for inside And outside key control (not included)
POWER Uses 1 9v battery (included). Normal battery life 1 Year. Can be powered by AC power by using either PP100 or AC9.
LOCK BOLT 1� throw heavy die-cast with reinforced
Steel inserts.
ALARM
Dual piezo siren measured at 95db”
$385.00 $308.00
“FCH-3792
Packaging powerful security into a compact size, the First Choice 3792 can be mounted on doors with stiles as narrow as 2” and includes a 1” forged steel latch bolt. Non-handed and available for doors up to 4 feet, the 3790 is a convenient solution for demanding, busy traffic conditions.
These durable devices are ANSI Grade I (500,000 cycles) and UL Listed. Striking anodized finishes are accented with high performance coatings on solid metal end clips.
Key Cylinder Preparation Include Cylinder Prep. Kit /without Key Cylinder
Application Narrow Stile Application
Bolt 1” Steel Latch Bolt with 1/2” Throw
Device lengths 36″”, 42″”, 48″”
Door Width 36″”, 42″”, 48″”
Hand non-handed
Limited Manufacturer Warranty 2 Years
Fire Rated No
Dimensions 2 1/2” Push Bar Height
41 5/16” Centerline Height Typical
Center Case Cover – 6 5/8” Tall by 1 1/4” Wide
Certifications ANSI A156.3 – 2008 Grade “
$485.00 $388.00
“Since Hager’s inception in 1849 their Hager brand commercial hinges have always been made right here in America. And it’s not just hinges. The bulk of Hager’s traditional door hardware lines are American-made.
“
$499.00 $399.20
“Since Hager’s inception in 1849 their Hager brand commercial hinges have always been made right here in America. And it’s not just hinges. The bulk of Hager’s traditional door hardware lines are American-made.
“
$499.00 $399.20
“Since Hager’s inception in 1849 their Hager brand commercial hinges have always been made right here in America. And it’s not just hinges. The bulk of Hager’s traditional door hardware lines are American-made.
“
$379.00 $303.20
“Since Hager’s inception in 1849 their Hager brand commercial hinges have always been made right here in America. And it’s not just hinges. The bulk of Hager’s traditional door hardware lines are American-made.
Specs
Cylinders/Cores
Requires the use of a Rim cylinder, 3901, sold separately
Escutcheons
3″” x 11″” (76 mm x 298.5 mm)
Functions
03 – Key retracts latchbolt
Notes
Supplied with retaining cup for use with 161 door prep
Projection
1-3/4″” (44.5 mm)
Pull CTC
5-1/2″” (140 mm)
Warranty
Five-years”
$175.00 $140.00
“Since Hager’s inception in 1849 their Hager brand commercial hinges have always been made right here in America. And it’s not just hinges. The bulk of Hager’s traditional door hardware lines are American-made.
Specs
Cylinders/Cores
Requires the use of a Rim cylinder, 3901, sold separately
Functions
03 – Key retracts latches
Notes
Cylinder cup included with trim for retrofitting doors prepped for bored locks (ANSI A115.2)
Retaining cup, 2-649-0137, included for 161 door prep
Projection
1″” (25 mm)
Warranty
Five-years”
$80.00 $64.00
“Commercial Trim Knob For Push Bar
56mm Dia. Knob
78mm Length
2 Keys SC4 Keyway”
$59.00 $47.20
“Panic Exit Device
Easy installation
UL listed (UL 305)
Modular and Reversible
Suitable for single or double doors
Fully adjustable
Dogging / undogging system
To use an exit trim with this device you MUST use a compatible Gaab Exit Trim (listed below)”
$140.00 $112.00
“The Rim Type Panic Bar Exit Device – 32″” bar for 28″” to 36″” doors – comes in an Aluminum Finish. Grade 1 Exit Device is manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications. Device Type Rim Type Panic Bar Exit Device
Device Length 32″” length made for 28″” to 36″” doors
Door Thickness 1-3/4″” standard up to 2-1/4″”
Handing Reversible for Left or Right Handed Doors
Material Push bar made of extruded aluminum / anodized material
Includes Roller Strike, 6 Thru Bolts, Mounting Bracket w/ Screws
Projection Anodized Aluminum
Grade Grade 1″
$169.99 $135.99
The Rim Type Panic Bar Exit Device – 32″ bar for 28″ to 36″ doors – comes in a Black Finish. Grade 1 Exit Device is manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications.
$271.00 $216.80
“The Premium Heavy Duty Narrow Stile Rim Type Exit Device is 48 In. in length and comes in an Aluminum Finish. The item is suitable for doors where there is no projection on the face. Manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications.
More Info Below Device Type Narrow Stile Rim Exit Device (No Trim)
Certifications Grade 1
Device Length 42″” to 48″” doors
Door Thickness Suits 1-3/4″” standard up to 2-1/4″”
Handing Field Reversible
Material Pushbar made of extruded aluminum, clad or anodized material
Stile Width Minimum 2″” Stile
Projection 2-5/8″” when fully projected, 1-5/8″” when dogged
Finish Anodized Aluminum”
$220.00 $176.00
“The Premium Heavy Duty Narrow Stile Rim Type Exit Device is 48 In. in length and comes in a Duranodic Bronze Finish. The item is suitable for doors where there is no projection on the face. Manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications.Device Type Narrow Stile Rim Exit Device (No Trim)
Certifications Grade 1
Device Length 42″” to 48″” doors
Door Thickness Suits 1-3/4″” standard up to 2-1/4″”
Handing Field Reversible
Material Pushbar made of extruded aluminum, clad or anodized material
Stile Width Minimum 2″” Stile
Projection 2-5/8″” when fully projected, 1-5/8″” when dogged
Finish Duranodic Bronze Finish”
$199.00 $159.20
“The Rim Type Panic Bar Exit Device – 34.5″” for 28″” to 36″” doors – comes in an Aluminum Finish. Grade 1 Exit Device is manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications.Device Type Rim Type Panic Bar Exit Device
Device Length 34.5″” length made for 28″” to 36″” doors
Door Thickness 1-3/4″” standard up to 2-1/4″”
Handing Reversible for Left or Right Handed Doors
Material Push bar made of extruded aluminum / anodized material
Projection Anodized Aluminum”
$179.00 $143.20
