“Commercial Trim Knob For Push Bar
56mm Dia. Knob
78mm Length
2 Keys SC4 Keyway”

The Rim Type Panic Bar Exit Device – 32″ bar for 28″ to 36″ doors – comes in a Black Finish. Grade 1 Exit Device is manufactured of extruded anodized aluminum, it is durable enough for the most demanding applications.

“FCH-3792

Packaging powerful security into a compact size, the First Choice 3792 can be mounted on doors with stiles as narrow as 2” and includes a 1” forged steel latch bolt. Non-handed and available for doors up to 4 feet, the 3790 is a convenient solution for demanding, busy traffic conditions.

These durable devices are ANSI Grade I (500,000 cycles) and UL Listed. Striking anodized finishes are accented with high performance coatings on solid metal end clips.
Key Cylinder Preparation Include Cylinder Prep. Kit /without Key Cylinder
Application Narrow Stile Application
Bolt 1” Steel Latch Bolt with 1/2” Throw
Device lengths 36″”, 42″”, 48″”
Door Width 36″”, 42″”, 48″”
Hand non-handed
Limited Manufacturer Warranty 2 Years
Fire Rated No
Dimensions 2 1/2” Push Bar Height
41 5/16” Centerline Height Typical
Center Case Cover – 6 5/8” Tall by 1 1/4” Wide
Certifications ANSI A156.3 – 2008 Grade “

“M9900 Exit Devices from Marks USA offer a simple, heavy-duty, easily installed solution where high-quality panic & fire listed hardware is needed. These extremely durable, Grade 1 exit devices are perfect for high impact applications such as schools, universities & other institutional or commercial buildings, and retrofit all popular preps. The heavy-duty cast chassis provides superior durability, while the smooth reduced projection touchbar assembly minimizes catch hazards. To help alleviate the problem of end caps breaking off due to abuse from carts, they have a mitered steel flush mounted Panic Protector End Cap. End Cover Stainless steel beveled “Panic Protector” design
Strike Roller strike
Rail Assembly Heavy Gauge Stainless Steel
Dead latch Bolt: Stainless Steel 3/4” throw
Door Width
36″ device for up to 3′ wide opening
Dogging feature Allen Key
Latch Bolt
3/4″ throw, stainless steel
Dogging Allen wrench type
Finish US32D – Satin Stainless
Certifications
UL listed: For “Panic Hardware”
ANSI: ANSI 156.3 (2001), requirements for Grade 1
Manufacturer Warranty”
