“The Cal-Royal NM8453’s Latch bolt is retracted by the lever from either side unless the outside lever is locked by an operating toggle button. Deadbolt projected by key from outside or by thumb turn from inside. Both the deadbolt and latch bolt are retracted by the inside lever simultaneously. The latch bolt is deadlocked when the outside lever is locked or when the deadbolt is projected. The outside lever is unlocked by the toggle button if the deadbolt is retracted. The inside lever is always free for immediate egress.

Features:

BHMA Certified Lifetime Warranty
Conforms to federal specification type 86; and to all dimensional and operational performances of ANSI A156.13-1 80, Series 1000, Extra Heavy Duty
UL listed 3-hour rating, conforms to standards UL10C and UBC 7-2-1997
Rust-proof heavy duty 2 ¾”” backset lock case
Individual spring to prevent lever sag, easily reversible
Forged brass lever handles exceed requirements of ADA (American Disability Act)
Auxiliary latch bolt
Armored front plate conceals lock mounting screws
1″” throw heavy duty deadbolt with anti-saw hardened pins
Heavy duty ¾”” latch bolt with anti-friction latch, easily reversible”

“PN: S6188
For use with model numbers: DL1200, DL1300, PDL1300
Includes: 1LH and 1RH”

“The Schlage L Series has long been the benchmark for mortise locks.
Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of almost every application.

Features

Grade 1
UL Listed & Fire Rated up to 3 Hours
Unsecured failures prevented by break-away spindle, also providing easy spindle replacement
Universal lock case featuring ten functions in one case Lock Function
9080-Storeroom – Latchbolt retracted by key outside or by knob/lever inside.
Outside knob/lever is always inoperative. Auxiliary latch
deadlocks latchbolt when door is closed. Inside lever is
always free for immediate egress.

Handing Right Hand
Door Thickness 1-3/4″” (44 mm)
Cylinder No Cylinder – Lock Body Only
Backset 2-3/4″” (70 mm) only
Bolt 1″” (25 mm) throw stainless steel deadbolt
Latch
3/4″” (19 mm) throw stainless steel latch with anti-friction tongue
Material Stainless Steel / Zinc
Case size 4-7/16″” x 3-5/8″” x 1″” (113 mm x 92 mm x 25 mm)
Spacing Knob or lever to cylinder: 3 7/8″” (98 mm); knob or lever to thumbturn hub: 2 11/16″” (68 mm)
Strike 1-1/8″” x 3-1/2″” (29 mm x 89 mm) with dust box
Certifications
ANSI/BHMI Certified A156.13-2012
Commercial Grade 1
Lock Body Mortises Inside the Edge of the Door
UL Listed for 3 Hour Fire Door
Manufacturer Warranty Limited lifetime mechanical warranty”

“The Schlage L Series has long been the benchmark for mortise locks.
Beyond strength and security – it offers tremendous flexibility to allow it to meet the needs of almost every application Lock Function
ANSI F04 Entry/Office lock – Latchbolt retracted by knob/lever from either side unless outside is made inoperative by key outside or by turning inside thumb turn

Handing Right Hand
Door Thickness 1 3/4″” (44 mm)
Cylinder No Cylinder – Lock Body Only
Backset 2 3/4″” (70 mm) only
Bolt 1″” (25 mm) throw stainless steel deadbolt
Latch
3/4″” (19 mm) throw stainless steel latch with anti-friction tongue
Material Stainless Steel / Zinc
Case size 4 7/16″” x 3 5/8″” x 1″” (113 mm x 92 mm x 25 mm)
Spacing Knob or lever to cylinder: 3 7/8″” (98 mm); knob or lever to thumbturn hub: 2 11/16″” (68 mm)
Strike 1 1/8″” x 3 1/2″” (29 mm x 89 mm) with dust box
Certifications
ANSI/BHMI Certified A156.13-2012
Commercial Grade 1
Lock Body Mortises Inside the Edge of the Door
UL Listed for 3 Hour Fide Door
Manufacturer Warranty Limited lifetime mechanical warranty”
